FEATURES
- JBL Premium Transducers
- 1000 W highly efficient Class-D amplification
- Maximum SPL Output: 134dB
- System Type: Self powered 18” Subwoofer
- Frequency Range (-10dB): 31Hz – 150Hz
- Frequency Response (- 3dB): 42.5Hz – 150Hz
- Bluetooth Control
• 3 Parametric EQs + Hi & Lo Shelf • Gain and Delay • Save and Recall settings • Polarity Inversion - JBL Engineered Crossover Presets
• 80 Hz • 100 Hz • 120 Hz • EON - M20 Pole Cup
- Rugged, stage-ready Duraflex enclosure
SPECIFICATIONS
| System Type | Self powered 18” Subwoofer | |
| Maximum SPL Output | 134 dB | |
| Frequency Range (-10 dB) | 31Hz –150Hz | |
| Frequency Response (-3 dB) | 42.5Hz – 150Hz | |
| System Power Rating | 1000W Peak, 500W Continuous | |
| Input Impedance | 22k (balanced) | |
| Line Input Gain | 0 to 36 dBu | |
| Line | +14dBu | |
| Connectors | 2 x Balanced XLR-1/4” combination inputs; 2 x male XLR loop thru out |
|
| LED Indicators | Front Power LED (Defeatable, white) Rear Power LED (White), Bluetooth (Blue), EQ+ (Green) Preset (Green) Signal (Green) Limit (Orange) | |
| Cooling | Passive | |
| AC Power Input | 100-120VAC 50/60Hz; 230-240VAC 50/60Hz | |
| AC Power Consumption (120V~) | 1/8th Power – 1.14A (Max), 1/4th Power – 1.71A (Max), 1/3rd Power – 2.03A (Max) |
|
| LF Driver | 1 x JBL 618H 457mm (18”) woofer with 2” voice coil | |
| Crossover Frequency | Selectable; 80 Hz, 100 hz, or 120 Hz | |
| Material | Duraflex coated wooden enclosure | |
| Suspension/Mounting | M20 Threaded Pole Cup | |
| Handles | 2 | |
| Grille | Powder coated, Obsidian, perforated steel with acoustically transparent black cloth backing | |
| Dimensions (L x W x H) | 582mm x 668mm x 645mm (22.9” x 26.3” x 25.4”) |
|
| Weight | 72 lbs (35.5 kg) | |
| Shipping Weight | 91 lbs (41.2 kg) | |
| Shipping Dimensions (L x W x H) | 803mm x 768mm x 631mm (31.6″ x 30.2″ x 25.1″) |
