ModelBar 2.1 Deep Bass CNTR (Soundbar Unit), Bar 2.1 Deep Bass SUB (Subwoofer Unit)
Power supply100 – 240V AC, ~ 50/60Hz
Total speaker power output (Max. @THD 1%)300W
Output power (Max. @THD 1%):Yes
2 x 50W (Soundbar); 200W (Subwoofer)Yes
Transducer4 x race track drivers + 2 x 1” tweeter (Soundbar); 6.5” (Subwoofer)
Soundbar and Subwoofer standby power<0.5W
Operating temperature0°C – 45°C
HDMI Video output (With Audio return channel)1
HDMI version1.4
HDMI Video input1
Frequency response40Hz – 20KHz
Audio inputs1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)
Dimensions (W x H x D):Yes
965 x 58 x 85 (mm) / 38” x 2.28” x 3.35” (Soundbar);Yes
240 x 240 x 379 (mm) / 8.9” x 8.9” x 14.6” (Subwoofer)Yes
Weight2.16 kg (Soundbar);
5.67 kg (Subwoofer)Yes
Packaging dimensions (W x H x D)1045 x 310 x 405mm
Packaging weight (Gross weight)10.4kg
USB portType A
USB rating5V DC/ 0.5A
Supporting file formatmp3, wav
MP3 CodecMPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
MP3 sampling rate16KHz – 48 KHz
MP3 bitrate80kbps – 320kbps
WAV sample rate16KHz – 48 KHz
WAV bitrateUp to 3000kbps
Bluetooth version4.2
Bluetooth profileA2DP V1.3, AVRCP V1.5
Bluetooth frequency range2402MHz-2480MHz
Bluetooth Max. transmitting power<10dBm (EIRP)
Modulation TypeGFSK, π/4 DQPSK, 8DPSK
5G Wireless frequency range5736.35 – 5820.35MHz
5G Max. transmitting power<9dBm (EIRP)
Modulation Typeπ/4 DQPSK
